1-Channel HDTVI Video Installation Kit | ST, SM

SKU:HDTVITR1005

Free Ground Shipping For Online Store Orders
Free Unlimited Support
Lifetime Warranty

The VERSITRON VersiVision HDTVITR1005 is a 1-channel HD-TVI video installation kit designed to transmit digitally encoded HDTVI video over singlemode fiber optic cable. The complete kit includes the transmitter, receiver, power supplies, and 100 meters of singlemode fiber, providing a convenient solution for extending HDTVI camera connections over long distances.

The HDTVITR1005 supports 8-bit digitally encoded video and is compatible with NTSC, PAL, and SECAM camera systems. Its plug-and-play design requires no electrical or optical adjustments, while LED indicators provide convenient system status monitoring. The singlemode version supports transmission distances of up to 30 km.

Product Highlights

1-channel HDTVI video transmission
8-bit digitally encoded video
Singlemode fiber optic transmission
Up to 30 km transmission distance
ST optical connectors
1310nm optical wavelength
Compatible with NTSC, PAL, and SECAM video systems
Supports 1280H/25F, 1280H/30F, 1280H/50F, and 1280H/60F
Plug-and-play installation
No electrical or optical adjustments required
LED indicators for system monitoring
Standalone or rack-mount installation
Compatible with the FVC18 18-slot chassis
Includes transmitter, receiver, power supplies, and 100 meters of singlemode fiber

View full details

1-Channel HDTVI Video Over Singlemode Fiber

The HDTVITR1005 provides a complete fiber optic solution for extending one channel of HDTVI video from a camera location to a monitoring or recording location. The transmitter connects to the HDTVI camera, while the receiver is installed at the monitoring end of the fiber link.

The VersiVision HD platform uses a single fiber optic cable between the transmitter and receiver and is designed for adjustment-free installation and operation.

Digitally Encoded HD-TVI Video

The HDTVITR1005 supports 8-bit digitally encoded HD-TVI video and is directly compatible with NTSC, PAL, and SECAM camera systems. The optimized optical modules support 1280H/25F, 1280H/30F, 1280H/50F, and 1280H/60F formats.

30 km Singlemode Fiber Transmission

The HDTVITR1005 uses singlemode fiber with a 1310nm optical wavelength and supports a maximum transmission distance of 30 km. The VersiVision product model table identifies the HDTVIT1005 transmitter and HDTVIR1005 receiver as the 1-channel HDTVI singlemode versions.

Plug-and-Play Installation

The HDTVITR1005 is designed for straightforward installation without electrical or optical adjustments. LED indicators provide immediate visibility into system operating status.

A typical installation places the transmitter at the camera end and the receiver at the monitoring end, connected by a single fiber optic cable.

Technical Specifications

Specification	HDTVITR1005
Video	1-Channel HD-TVI
Video Input	0.6–2.0 Vp-p (75 Ohms)
Bandwidth	5 Hz–8 MHz
Bit Resolution	8-Bit
Differential Gain	< ±1%
Differential Phase	< ±1°
Tilt	< 1%
S/N Ratio	60 dB (Weighted)
Fiber Type	Singlemode
Optical Wavelength	1310nm
Maximum Distance	30 km
Number of Fibers	1
Optical Connector	ST
Video Connector	BNC
Optical Emitter	Laser Diode
Power Supply	5VDC, 2A
MTBF	>100,000 Hours
Operating Temperature	-35°C to +65°C
Storage Temperature	-45°C to +85°C
Relative Humidity	0% to 95% (Non-Condensing)
Installation	Standalone or Rack-Mount
Rack-Mount Chassis	FVC18 18-Slot Chassis

These specifications are from the VersiVision HD datasheet. The 1-channel unit dimensions are 4.33 × 4.09 × 1.10 inches.

Complete HDTVI Installation Kit

The HDTVITR1005 installation kit includes:

HDTVI transmitter
HDTVI receiver
Power supplies
100 meters of singlemode fiber optic cable

This provides the primary components needed to establish a 1-channel HDTVI fiber optic video link.

Standalone or Rack-Mount Installation

The HDTVITR1005 can be deployed as a standalone solution or installed in the VERSITRON FVC18 18-slot rack-mount chassis. The VersiVision HD modules are hot-pluggable when installed in the FVC18 chassis.

HDTVI Fiber Optic Video Applications

The HDTVITR1005 is suited for applications requiring long-distance extension of HDTVI camera signals over singlemode fiber, including:

Security and surveillance systems
CCTV monitoring
Commercial security installations
Industrial video monitoring
Transportation and infrastructure monitoring
Remote camera installations
Centralized video monitoring

Why Choose the VERSITRON HDTVITR1005?

The HDTVITR1005 combines 1-channel HDTVI video transmission with a complete singlemode fiber installation kit. With the transmitter, receiver, power supplies, and 100 meters of fiber included, it provides a straightforward way to extend HDTVI camera connections over distances up to 30 km.

VERSITRON — Safeguarding Communications Since 1958

Since 1958, VERSITRON has developed fiber optic communication solutions for video, data, and networking applications. The VersiVision product family supports HD-CVI, AHD, and HD-TVI video transmission over fiber.

Technical Specifications:

Video Input

0.6 ~ 2.0 Volt pk-pk (75 Ohms)

Video Interface

HD-TVI

Input/Output Channels

Bandwidth

5 Hz ~ 8 MHz

Bit Resolution

8-Bit

Differential Gain

<±1%

Differential Phase

<±1°

Tilt

< 1%

S/N Ratio

60dB (Weighted)

Wavelength

1310nm

Number of Fibers

Optical Connector

Video Connector

BNC

Power Supply

5VDC, 2A

MTBF

>100,000 Hours

Operating Temperature

-35°C to +65°C

Storage Temperature

-45°C to +85°C

Relative Humidity

0% to 95% (non-condensing)

All of the VersiVision HD installation kits are available for standalone applications and include: Transmitter, Receiver, Power Supplies & 100 meters of fiber. Please give us a call (1-800-537-2296) or open a chat with any questions. We look forward to discussing your application with you!

Key Features of 1 Channels HDTVI Video Transmitter & Receiver

8-Bit Uncompressed Video Transmission
Digitally Encoded
NTSC, PAL, SECAM Video Compatible
Simplex or Full Duplex Data
WDM Technology for Higher Reliability
Standalone or Rackmount into FVC18 Chassis (Hot Pluggable) Simultaneous Transmission of Video and Data VersiVision Chassis, HD-SDI, HDMI.

HD Units Spec

HD Video Only Manual

Triad

1-Channel HDTVI Video Installation Kit | ST, SM (HDTVITR1005) is used across the following Applications:

Singlemode HD-TVI Camera Links

Provides a dedicated optical video connection for one HD-TVI camera.
Uses one fiber with the specified 1310nm wavelength.
BNC video connectivity supports compatible HD-TVI equipment.
ST optical connectivity matches the specified fiber interface.

Remote Building Entrance Cameras

Supports a single HD-TVI camera monitoring a remote building entrance.
Singlemode fiber provides the specified optical video connection.
5 Hz to 8 MHz bandwidth supports the HD-TVI video interface.
60dB weighted S/N ratio supports the specified signal performance.

Facility Gate Surveillance

Provides one dedicated HD-TVI link for a facility gate camera.
1310nm optical transmission matches the supplied specification.
Operating temperature from -35°C to +65°C supports varied site conditions.
Less than 1% tilt supports the specified video characteristics.

Parking Access Camera Links

Connects one HD-TVI camera positioned at a parking access area.
One fiber supports the specified optical video transmission.
8-bit resolution matches the stated HD-TVI configuration.
Less than 1% differential gain supports the specified video performance.

Warehouse Entry Surveillance

Supports a dedicated HD-TVI camera at a warehouse entry location.
ST optical connectivity supports the specified single-fiber connection.
Less than 1° differential phase supports the stated signal characteristics.
MTBF greater than 100,000 hours supports long-term deployment.

Industrial Area Monitoring

Provides optical HD-TVI connectivity for one industrial-area camera.
Wide operating temperature capability supports varied industrial locations.
5 Hz to 8 MHz bandwidth supports the specified video signal.
60dB weighted S/N ratio supports the defined transmission quality.

Manufacturing Floor Cameras

Supports a dedicated HD-TVI camera for a manufacturing area.
1310nm wavelength provides the specified optical configuration.
One fiber keeps the video connection dedicated to the camera.
5VDC, 2A power supply matches the specified requirement.

Campus Building Surveillance

Connects one HD-TVI camera at an individual campus building.
Singlemode fiber supports the specified optical video connection.
BNC video connectivity matches the supplied video interface.
Operating temperatures from -35°C to +65°C support varied locations.

Government Facility Monitoring

Provides one HD-TVI channel for a dedicated government facility camera.
1310nm wavelength supports the specified singlemode fiber link.
Greater than 100,000-hour MTBF supports extended installation requirements.
0% to 95% non-condensing humidity tolerance supports varied environments.

Transportation Facility Cameras

Supports a dedicated HD-TVI camera at a transportation facility.
One fiber provides the specified optical video connection.
5 Hz to 8 MHz bandwidth supports the HD-TVI interface.
Less than 1% differential gain supports the specified video performance.

Utility Site Surveillance

Provides dedicated HD-TVI video connectivity for a utility site camera.
Singlemode transmission uses the specified 1310nm wavelength.
Storage temperature is specified from -45°C to +85°C.
MTBF greater than 100,000 hours supports long-term installation use.

Critical Infrastructure Camera Links

Supports one HD-TVI camera for a dedicated infrastructure monitoring point.
Low differential gain of less than ±1% supports the specified signal characteristics.
Low differential phase of less than ±1° supports the defined video performance.
Single-fiber optical transmission uses the specified 1310nm wavelength.

Perimeter Security Cameras

Provides a dedicated HD-TVI connection for one perimeter camera.
Operating temperature from -35°C to +65°C supports outdoor site conditions.
0% to 95% non-condensing humidity support suits varied environments.
ST optical connectivity supports the specified single-fiber installation.

Parking Area Observation

Connects one HD-TVI camera for a defined parking observation zone.
1310nm wavelength supports the supplied singlemode optical configuration.
60dB weighted S/N ratio supports the specified video signal quality.
Less than 1% tilt supports the stated video performance.

Hospitality Property Cameras

Supports a dedicated HD-TVI camera at a hotel or hospitality property.
BNC video connection supports compatible HD-TVI equipment.
8-bit resolution supports the defined video transmission format.
One fiber provides the specified optical video connection.

Security Control Room Feed

Provides one HD-TVI video channel for a dedicated monitored camera.
5 Hz to 8 MHz bandwidth supports the specified video interface.
60dB weighted S/N ratio supports the defined video signal quality.
ST optical and BNC interfaces match the specified equipment connections.

Outdoor Access Monitoring

Suitable for one HD-TVI camera monitoring an outdoor access point.
Operating temperature range is -35°C to +65°C.
Storage temperature range is -45°C to +85°C.
Relative humidity support is 0% to 95% non-condensing.

HD-TVI Fiber Retrofit

Provides optical connectivity for compatible single-channel HD-TVI systems.
Supports one HD-TVI video input and output channel.
1310nm wavelength matches the specified singlemode configuration.
BNC video and ST optical interfaces support the defined connections.

Remote Facility Camera Links

Connects one HD-TVI camera for monitoring a remote facility location.
Singlemode optical transmission uses one fiber at 1310nm.
8-bit resolution supports the specified video configuration.
Greater than 100,000-hour MTBF supports extended operation.

Dedicated CCTV Expansion

Adds one optical HD-TVI video channel to a compatible surveillance system.
Suitable where a dedicated single-camera link is required.
5VDC, 2A power supply matches the stated equipment specification.
1310nm singlemode transmission supports the specified optical connection.

Versitron is one of the leading (HDTVITR1005) 1-Channel HDTVI Video Installation Kit | ST, SM manufacturing companies in the USA (based in Delaware). If your industry or installation location isn't listed above, feel free to reach out to us!

Buy the Best 1-Channel HDTVI Video Installation Kit | ST, SM with Video over Singlemode Fiber from VERSITRON at a Competitive Price!
