10GB SFP Module | 850nm, LC, MM

SKU:10GBMM

Free Ground Shipping For Online Store Orders
Free Unlimited Support
Lifetime Warranty

The VERSITRON 10GBMM 10Gb Ethernet SFP Module provides high-speed 10Gbps fiber optic connectivity over 850nm multimode fiber. Designed for compatible 10Gb networking equipment, this LC fiber module provides a flexible solution for high-bandwidth connections in data centers, enterprise networks, campus networks, and other applications requiring reliable short- to medium-distance 10Gb fiber connectivity.

The 10GBMM supports multiple multimode fiber types, with transmission distances of up to 300 meters over OM3 fiber, making it an effective choice for high-speed network connections where multimode fiber infrastructure is already installed.

Product Highlights

10Gbps Ethernet
850nm Wavelength
Multimode Fiber (MMF)
LC Fiber Connector
Up to 300m over OM3 fiber
Up to 80m over 50µm multimode fiber
Up to 30m over 62.5µm multimode fiber
Industry-Standard SFP Form Factor
Hot-Pluggable
3.3V Single Power Supply
TTL Signal Detect Indicator
Operating Temperature: 0°C to 70°C
TX Power: -7 to -1 dBm
RX Sensitivity: < -10 dBm

View full details

10Gb Ethernet SFP Module for Multimode Fiber

The VERSITRON 10GBMM is a 10Gb Ethernet fiber optic SFP module designed to provide high-speed connectivity over multimode fiber. Operating at an 850nm wavelength with an LC connector, the module is suited for compatible 10Gb networking equipment used in enterprise networks, data centers, campus networks, and other high-bandwidth applications.

Multimode fiber provides a practical solution for shorter-distance 10Gb network connections. The 10GBMM supports several common multimode fiber configurations, allowing network designers to select the appropriate fiber based on the required transmission distance.

Flexible Multimode Fiber Distances

One of the advantages of the 10GBMM is its compatibility with multiple multimode fiber types.

Multimode Fiber	Maximum Distance
62.5µm MMF	30m
50µm MMF	80m
OM3 MMF	300m

These distances and the 850nm operating wavelength are specified in the VERSITRON Fiber Optic SFP Modules datasheet.

This makes the 10GBMM particularly useful for short- and medium-distance 10Gb fiber links, including connections within data centers, equipment rooms, enterprise facilities, and campus environments.

10GBMM Technical Specifications

Specification	10GBMM
Data Rate	10Gbps
Wavelength	850nm
Fiber Type	Multimode Fiber (MMF)
Connector	LC
62.5µm Fiber Distance	30m
50µm Fiber Distance	80m
OM3 Fiber Distance	300m
TX Power	-7 to -1 dBm
RX Sensitivity	< -10 dBm
Operating Temperature	0°C to 70°C

Designed for High-Bandwidth Network Connections

As networks move more data between switches, servers, storage systems, and other devices, 10Gb Ethernet provides significantly greater bandwidth than traditional Gigabit connections.

The 10GBMM provides a fiber-based 10Gb connectivity option for installations where multimode fiber is appropriate. Its compact pluggable design allows the module to be installed in compatible networking equipment without requiring a separate media converter.

The module is also hot-pluggable, uses a single 3.3V power supply, and includes a TTL signal detect indicator. The VERSITRON datasheet specifies a Class 1 laser compliant with EN 60825-1.

Typical Applications

The VERSITRON 10GBMM is well suited for:

Data Center Networks – High-speed connections between switches, servers, and other network equipment.
Enterprise Networks – 10Gb backbone and aggregation connections within buildings.
Campus Networks – High-bandwidth connections between network equipment across campus facilities.
Server and Storage Networks – High-speed connections for data-intensive applications.
Network Upgrades – Add 10Gb fiber connectivity to compatible networking equipment.
Security and Surveillance Networks – Support high-bandwidth video and data traffic.
Telecommunications Equipment – Provide short-distance 10Gb multimode fiber connectivity.
Enterprise Wiring Closets – Connect compatible 10Gb switches and network equipment.

10Gb Multimode SFP for Data Centers and Enterprise Networks

The 10GBMM is particularly useful when a network already uses multimode fiber and requires an upgrade to 10Gbps Ethernet. With support for OM3 fiber distances up to 300 meters, it can provide high-speed connectivity throughout many equipment rooms, data center environments, and building-level network installations.

For longer fiber distances, VERSITRON also offers 10Gb singlemode SFP modules. The 10GB10SM, for example, operates at 1310nm over singlemode fiber and supports distances up to 10km.

VERSITRON Fiber Optic SFP Modules

The 10GBMM is part of VERSITRON's broader family of fiber optic SFP modules. The product family includes 100Mbps, 1Gbps, and 10Gbps modules with multimode and singlemode fiber options and different transmission distances.

The VERSITRON SFP family also includes options for longer-distance singlemode applications, including 20km, 40km, 70km, 80km, and 100km Gigabit modules, as well as 40km and 80km 10Gb modules.

Why Choose VERSITRON?

VERSITRON provides fiber optic connectivity products designed for dependable network performance and long-term use. Our SFP modules are available across a range of speeds, fiber types, wavelengths, connectors, and transmission distances, helping network engineers select the appropriate optical solution for their application.

VERSITRON also provides free unlimited technical support and a lifetime warranty, giving customers access to technical assistance and long-term product support.

VERSITRON — Safeguarding Communications Since 1958

Since 1958, VERSITRON has been providing fiber optic communication and networking solutions. Our experience in fiber optic technology allows us to support customers across commercial, industrial, government, military, security, transportation, telecommunications, and other demanding network environments.

Need help selecting the right 10Gb SFP module? Contact VERSITRON for assistance with fiber type, transmission distance, and network requirements.

Yes, if you have a 10G 850nm SFP at one end of the fiber, the other side must be the same.

No it does not.

In theory, yes. SFP modules are supposed to be universal. However some are coded differently. We recommend asking the manufacturer of the switch device you are using if that switch will “read” any SFP module.

No, 10Gb must be matched with 10Gb.

Yes.

Multimode fiber optic cable in OM1, OM2, OM3, or OM4.

The operating temperature range of 10GBMM module is 0°C to +70°C.

It comes with a lifetime warranty.

Versitron SFP Modules Specifications

10GBMM Datasheet

10GB SFP Module (10GBMM) is used across the following Applications:

Data Center Server Connectivity

Connects compatible servers and network switches through 10Gbps multimode fiber links.
Supports short-distance fiber connections within data center racks and equipment areas.
Provides transmission distances up to 300m over OM3 multimode fiber.
Uses an LC connector for compatible fiber patching and network interfaces.

Switch-to-Switch Fiber Links

Connects compatible 10Gbps switches across nearby network distribution points.
Supports multimode fiber uplinks for local network infrastructure.
Provides link distances up to 80m over 50µm multimode fiber.
Enables 10Gbps fiber connectivity through compatible SFP+ interfaces.

Enterprise Network Backbones

Supports 10Gbps fiber connections between network switches in office buildings.
Connects network distribution equipment within the same building or floor.
Works with compatible 850nm multimode fiber infrastructure.
Provides an option for short-reach fiber backbone links using LC connections.

System Integrator Projects

Supports short-reach 10Gbps fiber links in integrated network installations.
Can be specified for compatible switches and network equipment with SFP+ interfaces.
Offers different supported distances according to the installed multimode fiber type.
Helps integrate fiber connectivity into building and campus network projects.

Government Office Networks

Connects compatible network equipment across offices and departmental areas.
Supports 10Gbps multimode fiber links within buildings.
Provides up to 300m of reach when used with OM3 multimode fiber.
Fits installations requiring compatible 850nm transceivers and LC fiber connections.

Military and Defense Facilities

Supports short-distance fiber connectivity between compatible network devices.
Can be used in facility networks where 10Gbps multimode links are suitable.
Provides LC-connected fiber links for compatible network interfaces.
Requires confirmation of equipment compatibility and environmental requirements before deployment.

University and Campus Networks

Connects compatible switches in campus buildings and internal network rooms.
Supports 10Gbps links between nearby network distribution points.
Provides up to 300m of transmission distance over OM3 multimode fiber.
Helps connect high-capacity network equipment over existing compatible fiber runs.

Healthcare Facility Networks

Connects compatible network switches in hospitals, clinics, and medical office buildings.
Supports short-reach 10Gbps fiber links between network rooms.
Uses 850nm multimode optics with an LC fiber connector.
Can support internal network infrastructure where the required fiber distance is within specification.

Financial Institution Networks

Provides 10Gbps fiber connectivity between compatible network devices.
Supports short-distance links in bank offices and internal data rooms.
Works with 50µm multimode fiber for distances up to 80m.
Supports OM3 multimode fiber connections up to 300m where compatible equipment is installed.

Industrial Office Networks

Connects compatible switches in industrial offices and facility network rooms.
Supports 10Gbps multimode fiber links between nearby network devices.
Operates within a specified temperature range of 0°C to 70°C.
Is suited to installations where the transceiver's temperature rating and fiber reach meet site requirements.

Telecommunications Equipment Rooms

Connects compatible 10Gbps network equipment over short multimode fiber runs.
Supports internal equipment-room links using 850nm optical transmission.
Provides an LC interface for compatible multimode fiber patch cords.
Can be used where the equipment supports the module's optical and interface specifications.

Video and Content Production Networks

Connects compatible network switches used in media production facilities.
Supports 10Gbps fiber links between nearby production and network equipment areas.
Provides up to 300m of reach over OM3 multimode fiber.
Can support network transport for media workflows when the connected equipment and bandwidth requirements are compatible.

Research and Laboratory Networks

Connects compatible servers, workstations, and switches in research facilities.
Supports 10Gbps multimode fiber links within laboratories and technical buildings.
Provides different supported reach limits for 62.5µm, 50µm, and OM3 fiber.
Uses an LC connector for compatible optical network interfaces.

Commercial Building Networks

Connects compatible network switches across floors or nearby equipment rooms.
Supports 10Gbps multimode fiber links within the specified distance limits.
Offers a reach of up to 300m over OM3 multimode fiber.
Fits building network installations that use compatible 850nm optical interfaces.

Multimode Fiber Network Upgrades

Supports upgrades to 10Gbps links where existing multimode fiber is compatible.
Works over 62.5µm fiber up to 30m and 50µm fiber up to 80m.
Supports transmission distances up to 300m over OM3 multimode fiber.
Requires verification of transceiver compatibility, fiber type, and link distance before installation.

Versitron is one of the leading (10GBMM) 10GB SFP module manufacturing companies in the USA (based in Delaware). If your industry or installation location isn't listed above, feel free to reach out to us!
